4-Stroke Petrol Engine Working Model — Air-Cooled Cutaway on Polished Wood Base, 450mm
4-Stroke Petrol Engine Working Model — Air-Cooled Cutaway on Polished Wood Base, 450mm
Couldn't load pickup availability
Working teaching model of an air-cooled 4-stroke petrol engine (Otto cycle) — cutaway construction reveals piston, valves, crankshaft, connecting rod, and camshaft in motion. Demonstrates the four strokes of internal combustion: Intake → Compression → Power (Combustion) → Exhaust. Valve operation clearly visible during rotation via hand crank. Mounted on polished wooden base with printed schematic diagram (labels the components + shows the Otto cycle phases). 450mm overall height. For mechanical engineering + automotive technology + physics teaching in universities, technical colleges, ITIs, polytechnics, and secondary science schools. $999.99 direct.
Specifications
| Type | 4-stroke Otto cycle petrol engine, air-cooled, cutaway working model |
|---|---|
| Configuration | Single cylinder, vertical piston, overhead valves |
| Cutaway view | Piston, cylinder, connecting rod, crankshaft, camshaft, valves clearly visible |
| Operation | Hand-crank rotation (student rotates crankshaft to demonstrate cycle) |
| 4-stroke phases demonstrated | 1. Intake · 2. Compression · 3. Power · 4. Exhaust |
| Base | Polished wooden base with printed schematic diagram + component labels |
| Overall height | Approximately 450 mm (17.7") |
| Base dimensions | ~350 × 250 mm (14" × 10") — desktop demonstration size |
| Materials | Metal engine components (steel + aluminum), wood base, painted labels |
| Weight | ~5-8 kg (compact, portable between classrooms) |
| Power | Manual (hand crank) — no electricity required |
| Country of origin | Made in India |
| Warranty | 1-year against manufacturing defects |
Teaching applications
- Mechanical engineering curriculum — Thermodynamics I / II, Engines + Combustion, Automotive Engineering
- Automotive technology programs — ITI + polytechnic + technical college
- University physics + thermodynamics — heat engines, Carnot cycle vs Otto cycle
- Secondary school physics — introduction to internal combustion (upper secondary + A-level)
- Automotive vocational training — mechanic training programs
- Museum + science center displays — interactive physics + engineering exhibits
- Corporate training — new-hire orientation at automotive manufacturers
- NGO STEM outreach — engineering education in developing regions
Best for
- Mechanical engineering departments (undergraduate labs)
- Automotive engineering programs
- ITI + polytechnic + technical college teaching labs
- University physics + thermodynamics teaching
- Automotive vocational + trade schools
- Secondary schools + junior colleges (physics)
- Science museums + educational displays
- International engineering education (India, Africa, LATAM, SE Asia)
- NGO STEM outreach programs
Buying for an engineering school, ITI, or STEM program?
- Volume pricing on 5+ orders — university multi-lab builds, ITI network procurement
- Net-30 invoicing for verified schools, universities, government training programs
- SAM.gov / GSA compliant procurement for federal + state education
- Bundle with 2-Stroke Engine Model + Diesel Engine Model + Steam Engine Model for complete IC engines teaching set
- Instructor's guide + student worksheets included on request
- International DDP shipping — huge STEM education growth in India, Africa, LATAM, SE Asia
- NGO / global education pricing on 10+ unit orders
FAQ
Does this actually run on petrol / fuel?
No — this is a CUTAWAY WORKING MODEL for teaching, not a functional engine. Students rotate a hand crank to demonstrate the 4-stroke Otto cycle mechanically. Valves open/close, piston moves up/down, camshaft rotates in synchronization — all mechanically driven by the crank. No fuel, no ignition, no combustion. Fully safe for classroom use.
What cycle phases can students see?
All 4 strokes of the Otto cycle: Intake (piston down, intake valve open), Compression (piston up, both valves closed), Power / Combustion (piston down, both valves closed — spark event indicated), Exhaust (piston up, exhaust valve open). Complete cycle = 2 crankshaft revolutions. Students see valve timing coordination via the camshaft.
Is a schematic / diagram included?
Yes — the polished wooden base includes a printed schematic diagram identifying each component (piston, cylinder, connecting rod, crankshaft, camshaft, intake valve, exhaust valve, spark plug location). Component labels included.
What other engine models do you have?
Complete IC engine teaching set: 4-stroke petrol (this), 2-stroke petrol, 4-stroke diesel, 2-stroke diesel, steam engine, Wankel rotary engine, Stirling engine. Bundle discount available on 3+ different types.
Is instructor training material included?
Instructor's guide covers: cycle explanation script, common student questions, suggested lab experiments (measure valve timing, calculate compression ratio, plot P-V diagram from cycle). Available on request.
